Smap3D Piping
CAD-integrated 3D Pipe Planning
Smap3D Piping is a powerful tool for 3D planning of piping in machines in plants. As an add-in for the well-known CAD systems SOLIDWORKS, Inventor and Solid Edge, it enables fully integrated design without media discontinuity. This turns a “normal” MCAD into a fully-fledged plant engineering solution!
Thanks to a wide range of functionalities, diverse automation routines and the use of pipe classes and standard parts libraries, even complex piping systems can be planned efficiently and reliably. Thanks to the connection to Smap3D P&ID, the definitions and information of the 2D flow diagrams can be transferred directly into Smap3D Piping and processed on this basis.
More information about Smap3D Piping
Further details on Smap3D Piping can be found on the Smap3D website.
